Atmospheric Water Generator Capacity 20 Liters to 40 Liters *


Dew Point-2

The process


The machine sucks in humid air from one side where there are filters which purify the air. The humid air in between goes though the process of condensation and produce water. The Step by Step Process is given on the right

Air Filteration

The sucked air goes through air filters to prevent micro-particles and dust from entering the appliance

Condensation

The Air then flows over condenser coil/cylinder and allows the moisture in air to turn vapor into liquid

Water Formation

Pure water is generated and it is free of any kind of impurities and contamination

Mineralisation

Before Final collection, minerals can be added with additional purification step.

Product Specifications


  • Water Production    :    20 litres per day
  • Dimensions of the Product
    • Height  :  70 cm
    • Width   :  30 cm
    • Length  :  50 cm
  • Net Weight    :  21 Kg (Empty)
  • Power (Compressor &  Fan)   : 450-500W
  • Input Power                                 :  (230V – 1~ – 50Hz)
  • Operating power                         :  400W / hr
  • Operational  Humidity                :  35% ~ 95%
  • Temperature of Cold Water       :  4ᵒC-10ᵒC
  • Water Storage Capacity             :  2 Liters
  • Automatic level sensors
  • Automatic timer

Technical specifications


  • POWER (WATT) : 400
  • VOLTAGE : 220-240
  • FREQUENCY : 5Hz
  • PHASE : SINGLE
  • WORKING RANGE OF HUMIDITY : 25% OR ABOVE
  • WORKING RANGE OF TEMPERATURE : 10 TO 50 ℃
  • REFRIGERANT : R134a
  • MASS OF REFRIGERANT : 220 GRAM
  • BIO MINERAL FILTER: 1 NOS.
  • U.V LIGHT FILTER : 1 NOS
  • FAN : 1 NOS. 540 CFM
  • DIMENSION : 68X45X43 CM
  • WEIGHT : 50KG

Daily water produced in Liters


temperature-in-celcius-vs-relative-humidity-in

Daily power consumption


  • PER HOUR : 550 WATTS
  • 24 HOURS : 13.2 KWHr
  • COST OF DAILY RUN FOR 24 HRS : Rs 130

CHECKOUT DEMO VIDEO


Check the working of Atmospheric Water Generator in Video

Frequently asked questions


A home based machine that condenses humidity in the atmosphere into clean drinking water.

Yes, this product has been tested in various geographical locations in India and also in various laboratories.

It has air filtration system which purifies the air sucked in also there is an additional filter which adds minerals to water for drinking purpose.

It can store up to 2 L. However there is a pipe outlet which enables you to have a continuous water supply.

The cost of Atmospheric Water Generator is Rs 16000

It is a very durable product can last easily up to life of a refrigerator

No, the water filter needs only min 35%RH to work which is available at every geographical location in the country.

Please see average humidity chart of that area by month and then correlate to water generated chart by humidity.

It is a very low maintenance device, you will need to change the filter only twice a year.

Please fill the form as Expression of interest and we shall contact you soon.

Request A Live Demo
